PT724A - Annual Event Timer Board, 365 Day 24 Hour, 12/24VAC/DC Input, Form C Relay Contacts rated 120VAC/28VDC at 10A - (Altronix)
PT724A - Annual Event Timer Board, 365 Day 24 Hour, 12/24VAC/DC Input, Form C Relay Contacts rated 120VAC/28VDC at 10A - (Altronix)



All repairs should be done by AAADM's Certified Technicians.
List Price: $179.54
Our Price: $138.22
Savings: $41.32


Availability:: Usually Ships in 24 Hours
Product Code: PT724A
Qty:

Description Technical Specs Extended Information

Features
    • Input
      • 12 to 24 volts AC or DC operation
    • Relay
      • Form "C" relay contacts are rated 10A @120VAC/28VDC.
      • Standby current: 10mA (relay off) 50mA (relay on).
    • Features
      • EE Prom memory protects against loss of programming due to power failure.
      • Accurate crystal controlled clock.
      • Momentary and/or Latching Events.
      • 50 individually programmed daily/weekly events.
      • Block programming capacity can accommodate a total of 350 events per week.
      • 10 programmable Holiday dates.
      • "First man in" option.
      • Standard or Daylight Savings Time settings.
      • Automatic compensation for leap year.
    • Visual Indicators
      • Alphanumeric LCD display simplifies programming.
    • Battery Backup
      • Built-in charger for 12VDC sealed lead acid or gel type batteries(Max charge current 100mA).
      • Optional lithium battery backup maintains clock.
      • Order Altronix part # LB2032.
    • Temperature
      • Operating -20ºC to 49ºC ( -4ºF to 120ºF).
      • Storage -25ºC to 70ºC ( -13ºF to 158ºF).
      • Relative Humidity 85% +/- 5%.
