    6062 - Multi-Purpose Timer Module, 12/24VDC - 1 Second to 60 Minutes - (

    Thumbnail Filmstrip of 6062 - Multi-Purpose Timer Module, 12/24VDC - 1 Second to 60 Minutes - ( Images

      Purchase 6062 - Multi-Purpose Timer Module, 12/24VDC - 1 Second to 60 Minutes - (

      SKU: 6062 6062 - Multi-Purpose Timer Module, 12/24VDC - 1 Second to 60 Minutes - (Altronix)

      All repairs should be done by AAADM's Certified Technicians.

      List Price: $39.64
      Our Price: $32.88
      Savings: $6.76

      Availability: Usually Ships in 24 Hours

      • Input
        • 12VDC or 24VDC operation is selectable.
      • Current Draw
        • Stand-by: 3mA, Relay energized: 40mA.
      • Relay
        • Selectable relay activation at the start or end of the timing cycle.
        • One (1) second momentary relay activation at the end of the timing cycle (eliminates the need to use two (2) timers for this function).
      • Features
        • Triggers via positive DC (+) voltage, dry contact closure, or removal of contact closure.
        • Quick and extremely accurate time range adjustment from 1 second to 60 minutes.
        • Built-in reset feature which cancels timing cycle.
        • Repeat (flasher/pulse) mode.
      • Visual Indicators
        • LED indicates relay is energized.
      • Electrical
          • Temperature:
            • Operating: 0° C to 49° C (32° F to 120° F).
            • Storage: - 20° C to 70° C ( - 4° F to 158° F).
        • Relative Humidity 85% +/- 5%.

      All use of Original Equipment Manufacturer Names are for reference only. Automatics & More is not a licensee of, or affiliated or connected with any Original Equipment Manufacturers. All repairs should be done by AAADM's Certified Technicians.
